Product range
VTR801, internal thread
![VTR801_lr.png](/storage/2BF913AB36D33A94335067C92E254F0EB25C573C4B030695130D74F1FC78D2C3/c35240f919a9439bbde728d658b4276c/160-160-0-png.Png/media/96bf800fa5004d41afdcbc83f74eab61/VTR801_lr.png)
![VTR801 front_A-01.png](/storage/5A8A56CE1CE5CFE07CC0EDEEE237ED4FE191E222FAD8A2669EB9F16E2D390ECD/50edd58314cb4af49e23ff7acf30e6b6/160-160-0-png.Png/media/7a393932f3a0495b83e8ef11f5377d06/VTR801%20front_A-01.png)
Art.no. | Reference | Connection E | Connection F | Connection G | A [mm] | B [mm] | C [mm] | D [mm] | Weight [kg] |
31405010 | VTR801 | Rp 1" | G ¾" | G 1" | 404 | 244 | 275 | 75 | 1,35 |
Installation support
Installation examples
![Installation examples](/storage/3C9DD33BF53DD62ABB9DC869261B87690219D42130FB14BD5223ABB89844E24A/c6c39c86da964442a7f6cdfd171833ab/png/media/b798552d5d5b44ffbbe84b8c349a71fd/VTR300_VTR801_1-01.png)
![](/storage/5C47D12D2FA2419821215A971E5E3D1F0E6BAC47E6E5F34CDF795DFD3A548409/5aaf3e6566ad4e91996c991609509a33/png/media/0ef486d6d4334b4d860d72287643fe81/VTR300_VTR801_2-01.png)
Documents
Name | Download |
Installation instruction VTR800 |
|
Technical data
Technical data
Pressure class: | PN 10 |
Working pressure: | 1,0 MPa |
Pipe: | PE-Xc, Ø8x1 mm, length: 1,5 m |
Media temperature, max. continuously: | +95 °C |
Media temperature, max. temporarily: | +110 °C |
Media temperature, min.: | 0 °C |
Material, Pipe PE-Xc: | PE-HD, without EVOH-Barrier layer |
Material, T-piece and other metal parts with fluid contact: | CUPHIN, Stainless steel |
Connections, Internal thread (Rp): | EN 10226-1 |
Connections, Internal thread (G): | ISO 228/1 |
Conformity
SI 2016 No. 1105 (UK)
4MS/KTW-BWGL
![](/storage/9CF6D7AADA0FB795039A11566B757EE82FD4CB94EA10E7C6432416313018511C/5754a223c81b462591e28bc831801505/png/media/2889d78c319c40439f2b95c7c31eda24/UA_Installation%20symbol_black.png)
ÜA R-15.2.4-22-17605 (AT)
Download area
Download area
Type | Preview | Download |
Data sheet | VTR800 |
|
Installation instruction | VTR800 |
|
Image | VTR801, high res |
|
